Alpha SiC power silicon carbide miron 0.7um 0.8um 1um
Alpha SiC power silicon carbide miron 0.7um 0.8um 1um is a fine silicon carbide polishing powder. It features high purity, uniform particle size, low free carbon content, low iron residue, and easy dispersion. Suitable for fine double-sided grinding and the preparation of polishing slurries, pastes, and other polishing products, it is used for polishing optical glass crystals, capillary glass, alloys, and other materials.
Characteristics of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um：
- The material has high hardness, with a Mohs hardness of 9.4-9.5, slightly lower than that of synthetic diamond abrasives.
- Produced through the water washing overflow precipitation process, the purity of silicon carbide is greater than 98.5%, with few impurities and low iron residue and free carbon content.
- The particle shape is moderate, without particularly prominent sharp corners, and also has a certain grinding edge.
- Good consistency in particle size and uniform particle size distribution.
Typical physical properties of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um:
| Mohs Hardness: | 9.4-9.5 |
| Vickers Hardness: | 3100-3400kg/mm2 |
| Knoop hardness | 2600kgf/mm2 |
| Specific Gravity: | 3.2g/cm3 |
| Particle shape: | Angular micron particle |
| Circularity | 0.87-0.92 |
| PH value | 6.8-7.1 |
| Bulk density(LPD): | 1.2-1.6 g/cm3 |
| Color: | Green |
| Melting Point: | Dissociated at about 2600 centigrade |
| Maximum service temperature: | 1900 centigrade |
| Friability | Friable |
| Thermal conductivity | 0.013 cal/cm2.sec (900°C) |
| Thermal expansion coefficient | 7-9 x10-6 /℃(0-1600°C) |
Chemical analysis of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um:
| Chemical Content | Standard Value | Typical Value |
| SiC | ≥98.0% | 98.22% |
| SiO2 | ≤0.20% | 0.13% |
| F,Si | ≤0.20% | 0.11% |
| Fe2O3 | ≤0.20% | 0.09% |
| F.C | ≤0.20% | 0.18% |
Particle size distribution of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um
Application of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um：
- Precision polishing of hard optical glass such as camera lenses.
- Sandblasting and sharpening of CNB cutting tools made of titanium alloys, cemented carbide, and other hard metals.
- Polishing and grinding quartz glass.
- Grinding hard stone, marble, granite, etc.
- Polishing PZT/piezoelectric ceramics.
- Sandblasting copper, copper alloys, brass products, etc.
- Surface treatment of diamond tools.
- Grinding diamonds, cinnabar, and other jewelry.
- Grinding precision parts made of other thin and brittle materials.
- Fire-retardant novel nano-aerogels.
- Fire-retardant and insulating materials such as sintered ceramics.
- High-quality brake additives for aircraft brakes, etc.
- Silicon carbide ceramic fillers.
Production details of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um
Packing of Alpha SiC power silicon carbide miron 0.7um 0.8um 1um
FAQ:
Q: What is the difference between green silicon carbide and black silicon carbide?
A: First of all, Green silicon carbide has higher purity of SiC(99%), black silicon carbide SiC purity is min 98%. Secondly, green silicon carbide is harder than black silicon carbide.
Q: What is the difference between FEPA,JIS standard of green silicon carbide powder?
A: Green silicon carbide powder FEPA standard is of Europen standard, it’s a coulter method based standard. Green silicon carbide powder JIS R 6001-2:2017 standard is of Japanese standard, it‘s a sedimentation method based standard.
Q: Is the green silicon carbide powder from you by air flow sieving or water sieving?
A: Our green silicon carbide powder is made by water sieving process. So the particles are of high consistency.
Q: What are the HS code and CAS NO. of silicon carbide?
A: HS code is 2849200000. CAS NO. is 409-21-2.
Q: Is there any restriction to export green silicon carbide powder from China?
A: Yes, it has to get an export license to export. We will provide it to custom.
Q: How many kgs of free samples can we get?
A: We provide free samples less than 1 kgs. Clients have to bear the express cost and DGM certificate cost.
Q: How do you inspection products before delivery?
A: We will check items of chemical, density, particle size distribution and packing before delivery. After delivery, we keep samples of each batch for 3 months.
Q: Do you demand MOQ?
A: MOQ is 1 bag, always goes 25kgs. The transportation cost will be higher than that of 1MT.
